| Modell | |
| Modell | 2026 Geely Galaxy M9 210 km 4WD Schwarz-Gold Smart Shine Edition |
| Energieart | Plug-in Hybrid (Raytheon EM-P AI PHEV) |
| Emissionsstandard | China vi b |
| Fahrzeug | |
| L×B×H (Mm) | 5205× 1999 × 1800 |
| Radstand (Mm) | 3030 |
| Track, F/R (Mm) | 1706 |
| Approach/Departure angle | 17 |
| Körperstruktur | 5-Tür 6-Sitz-SUV |
| Sitzanordnung | 2+2+2 |
| Sitzplatzkapazität | 6 |
| Bordsteingewicht (kg) | 2530 |
| Gesamtgewicht (kg) | 3030 |
| Fuel tank (L) | 60 |
| Boot volume (L) | 328 (seated) - - 2171 (erweitert) |
| Ziehenkoeffizient | 0.285 (60+ aero optimizations) |
| Bodenfreiheit (Mm) | 172 |
| Antriebsstrang | |
| Powertrain form | Plug-in Hybrid |
| Motor | 1.5T dedicated hybrid engine |
| Verschiebung (ml) | 1499 |
| Engine power (Ps) | 163 |
| Engine power (Kw) | @5000 rpm |
| Engine torque (N · m) | @2500-3500 rpm |
| Thermaleffizienz des Motors | 47.26% |
| Kraftstoff | 92# oder höher |
| Motortyp | Permanentmagnet-Synchron |
| Motor count | Triple motor (front+rear, P3+dual P4 distributed 4WD) |
| Front motor power (Kw) | 180 |
| Rear motor power (Kw) | 340 |
| Motorleistung (Kw) | 520 |
| Motordrehmoment (N · m) | 910 |
| Combined power (Kw) | 640 |
| Combined torque (N · m) | 1165 |
| Übertragung | 3DHT Evo dedicated hybrid transmission |
| Shifter | Column shifter |
| Fahren | Front-engine 4WD (electric 4WD) |
| 0-100 km/h (S) | 4.5 |
| Höchstgeschwindigkeit (km/h) | 210 |
| Batterie & Ladung | |
| Akku-Typ | Lfp (Shen Dun battery) |
| Cell brand | Catl |
| Batteriekapazität (kwh) | 41.46 |
| CLTC EV range (Kilometer) | 210 |
| WLTC EV range (Kilometer) | 170 |
| Kombiniertes CLTC-Sortiment (Kilometer) | 1300 |
| DC fast charge | 0.25 H (30%–80 %, ca.. 15 min) |
| AC charge | ca.. 6 H |
| Stromverbrauch | 22.9 |
| CLTC fuel consumption | 5.5 |
| WLTC -Kraftstoffverbrauch | 6.25 |
| V2l | Ja (max 6 Kw) |
| Chassis & Räder | |
| Frontfederung | Double-wishbone independent |
| Hinterradaufhängung | Five-link independent |
| Adaptive suspension | Magic-carpet intelligent suspension |
| CCD damper | ● |
| Luftfederung | Dual-chamber closed air suspension (F 80mm, R 95mm travel) |
| KI-Digital-Chassis | Lotus-tuned |
| Waltz-style turn | ● |
| Blow-out stability control | ● |
| Moose test | 83 km/h |
| Steering assist | Elektrische Stromhilfe |
| Körperstruktur | Monocoque |
| Brakes F/R | Belüftungsscheibe |
| Parking brake | Elektronische Feststellbremse |
| Tyre specification | 265/45 R21 (21-inch exclusive six-pointed star wheel) |
| Rad | 21-inch exclusive six-pointed star alloy wheel |
| Äußerlich | |
| Außenfarben | Exclusive Midnight Black + Gilded Gold two-tone (gold roof/mirrors/cladding) + optional Sky Isle Blue, usw. |
| Front light bar | Galaxy Ripples front full-width light w/ aurora-blue ADAS indicator |
| Tail lamp | Rising Sun tail lamp |
| AGS | Active grille shutter |
| Power tailgate | Power tailgate with memory |
| Panoramadach | Fixed panoramic glass roof (optional starry sky panoramic roof) |
| Cockpit & Schlau | |
| Center display | 30-inch 6K integrated sky screen |
| Instrument cluster | 12.66-Zoll digitaler Instrumentencluster |
| 2nd-row display | 17.3-inch 3K overhead screen |
| Ar-Skin | 32-inch AR head-up display |
| Infotainment | Flyme Auto 2.3 (Qualcomm Snapdragon 8295P) |
| AI BOX | Industry-first AI BOX on NVIDIA DRIVE, 200 TOPS AI, on-device 7B LLM |
| Voice assistant | 6-zone voice (end-to-end AI + flowing memory AI LLM) |
| Recognition | fingerprint recognition |
| Phone connectivity | Carlink |
| Smart control ring | Optional (health monitor + cockpit link + 2nd-row air gesture) |
| Drahtloses Laden | Dual 50W air-cooled wireless charging |
| USB charging | 60W front + 27W rear |
| Audio | 37-Lautsprecher -Audio -System |
| Umgebungsbeleuchtung | 256-color active ambient lighting |
| Vehicle refrigerator | 9.1L smart cool/warm refrigerator (−6℃—50℃) |
| Climate control | 3-zone auto + rear independent |
| Interior colors | Exclusive Nebula Red (top-grain leather w/ diamond stitching; Star River Wave door trim; suede-like soft-cloud headliner) |
| Sitzplätze & Komfort | |
| Upholstery | Top-grain bovine leather, exclusive diamond stitching & single-piece cutting |
| Front seats | Power adjust + vent + heat + Massage + Erinnerung |
| 2nd-row seats | Power adjust + vent + heat + Massage + folding table |
| 3rd-row seats | Power adjust + heat |
| One-touch seating | One-touch 8-mode adjustment |
| Steering wheel heating | Full-ring heated steering wheel |
| Heck Privatsphäre Glas | Multi-layer acoustic glass (Front & hinteren) |
| Adas | |
| ADAS system | Qianli Haohan H7 (G-ASD) (first Galaxy model equipped with H7) |
| ADAS chip | NVIDIA Thor-U |
| Compute | 700 Tops |
| Sensors | 27 Sensoren: 1 LIDAR + 11 cams + 12 ultrasonic + 3 mmWave |
| ADAS level | L2+ (mapless City NOA + door-to-door navigation + cross-floor auto exit + auto gate pass + ultra-narrow/dead-end auto parking + remote park-in) |
| Full-speed ACC | ● |
| Spurzentrierung | ● |
| Auto parking | ● |
| Remote/Memory parking | ● |
| Transparent chassis 540° | ● |
| Active safety plus | TOA tailgate opening alert |
| Sicherheit | |
| Airbags | 9 (inkl. front center & front/rear curtain) |
| Körper | Star Armor cage body (81.2% high-strength steel; 40.4% ≥1000MPa) |
| Max material strength | 2000 MPa |
| Body torsional rigidity | 32500 N·m/Grad |
| ABS/EBD/BA/TCS/ESP | ● |
| AEB/FCW | ● |
| LDW | ● |
| Fatigue/DMS | ● |
| TPMS | ● |
| Isofix | ● |
| Shen Dun battery safety | ● |
| DVR/Sentry | ● |
