| BYD Qin PLUS DM-i |
Qin PLUS DM 2024 DM-i Honor Edition 120KM Leading Edition |
Qin PLUS DM 2024 DM-i Honor Edition 120KM Beyond Edition |
Qin PLUS DM 2024 DM-i Honor Edition 120KM Excellence Edition |
| Basic Information |
| Manufacturer |
BYD |
BYD |
BYD |
| level |
Compact car |
Compact car |
Compact car |
| Energy Type |
Plug-in hybrid |
Plug-in hybrid |
Plug-in hybrid |
| Availability |
2024.02 |
2024.02 |
2024.02 |
| engine |
1.5L 110HP L4 Plug-in Hybrid |
1.5L 110HP L4 Plug-in Hybrid |
1.5L 110HP L4 Plug-in Hybrid |
| Pure electric range (km) Ministry of Industry and Information Technology |
101 |
101 |
120 |
| Pure electric range (km) NEDC |
120 |
120 |
120 |
| Pure electric range (km) WLTC |
101 |
101 |
101 |
| Comprehensive cruising range (km) Ministry of Industry and Information Technology |
1245 |
1245 |
1245 |
| Charging time (hours) |
Fast charge 0.5 hours Slow charge 5.55 hours |
Fast charge 0.5 hours Slow charge 5.55 hours |
Fast charge 0.5 hours Slow charge 5.55 hours |
| Fast charging capacity (%) |
30-80 |
30-80 |
30-80 |
| Maximum engine power (kW) |
81(110Ps) |
81(110Ps) |
81(110Ps) |
| Maximum motor power (kW) |
145(197Ps) |
145(197Ps) |
145(197Ps) |
| Engine maximum torque (N·m) |
135 |
135 |
135 |
| Maximum torque of motor (N·m) |
325 |
325 |
325 |
| Gearbox |
E-CVT continuously variable transmission |
E-CVT continuously variable transmission |
E-CVT continuously variable transmission |
| Length x width x height (mm) |
4765x1837x1495 |
4765x1837x1495 |
4765x1837x1495 |
| Body structure |
4-door 5-seater sedan |
4-door 5-seater sedan |
4-door 5-seater sedan |
| Maximum speed (km/h) |
185 |
185 |
185 |
| Official 0-100km/h acceleration time (s) |
7.3 |
7.3 |
7.3 |
| WLTC comprehensive fuel consumption (L/100km) |
1.58 |
1.58 |
1.58 |
| Power consumption per 100 km (kWh/100km) |
14.5kWh |
14.5kWh |
14.5kWh |
| Electric energy equivalent fuel consumption (L/100km) |
1.64 |
1.64 |
1.64 |
| Lowest state of charge fuel consumption (L/100km) WLTC |
4.6 |
4.6 |
4.6 |
| Minimum state of charge fuel consumption (L/100km) NEDC |
3.8 |
3.8 |
3.8 |
| Vehicle warranty period |
6 years or 150,000 km |
6 years or 150,000 km |
6 years or 150,000 km |
| Estimated total maintenance cost for 60,000 km |
5779.0 yuan |
396.0 yuan |
5779.0 yuan |
| Body |
| Wheelbase(mm) |
2718 |
2718 |
2718 |
| Front wheel track (mm) |
1580 |
1580 |
1580 |
| Rear wheelbase(mm) |
1590 |
1590 |
1590 |
| Body structure |
Sedan |
Sedan |
Sedan |
| Number of doors |
4 |
4 |
4 |
| Door opening method |
Swing door |
Swing door |
Swing door |
| Number of seats |
5 |
5 |
5 |
| Curb weight(kg) |
1620 |
1620 |
1620 |
| Full load mass (kg) |
1995 |
1995 |
1995 |
| Fuel tank capacity (L) |
48 |
48 |
48 |
| Luggage compartment volume (L) |
500 |
500 |
500 |
| Minimum turning radius |
5.5m |
5.5m |
5.5m |
| engine |
| Engine Model |
BYD472QA |
BYD472QA |
BYD472QA |
| Displacement (mL) |
1498 |
1498 |
1498 |
| Displacement(L) |
1.5 |
1.5 |
1.5 |
| Air intake form |
Naturally Aspirated |
Naturally Aspirated |
Naturally Aspirated |
| Engine layout |
Sideways |
Sideways |
Sideways |
| Cylinder arrangement |
L |
L |
L |
| Number of cylinders |
4 |
4 |
4 |
| Number of valves per cylinder |
4 |
4 |
4 |
| Compression ratio |
15.5 |
15.5 |
15.5 |
| Valve mechanism |
DOHC |
DOHC |
DOHC |
| Maximum horsepower (Ps) |
110 |
110 |
110 |
| Maximum power (kW) |
81 |
81 |
81 |
| Maximum power speed (rpm) |
6000 |
6000 |
6000 |
| Maximum torque (N·m) |
135 |
135 |
135 |
| Maximum torque speed (rpm) |
4500 |
4500 |
4500 |
| Engine thermal efficiency (%) |
43.04 |
43.04 |
43.04 |
| Fuel form |
Plug-in hybrid |
Plug-in hybrid |
Plug-in hybrid |
| Fuel grade |
92# |
92# |
92# |
| Oil supply method |
Multi-point EFI |
Multi-point EFI |
Multi-point EFI |
| Cylinder head material |
Aluminum Alloy |
Aluminum Alloy |
Aluminum Alloy |
| Cylinder material |
Aluminum Alloy |
Aluminum Alloy |
Aluminum Alloy |
| Environmental standards |
National VI |
National VI |
National VI |
|
Electric Motor |
|
|
| Motor Description |
Plug-in hybrid 197 hp |
Plug-in hybrid 197 hp |
Plug-in hybrid 197 hp |
| Motor Type |
Permanent magnet/synchronous |
Permanent magnet/synchronous |
Permanent magnet/synchronous |
| Total motor power (kW) |
145 |
145 |
145 |
| Total motor horsepower (Ps) |
197 |
197 |
197 |
| Total torque of the motor (N·m) |
325 |
325 |
325 |
| Maximum power of front motor (kW) |
145 |
145 |
145 |
| Maximum torque of front motor (N·m) |
325 |
325 |
325 |
| Number of drive motors |
Single motor |
Single motor |
Single motor |
| Motor layout |
Pre |
Pre |
Pre |
| Battery/Charging |
| Battery Type |
Lithium iron phosphate battery |
Lithium iron phosphate battery |
Lithium iron phosphate battery |
| Battery Feature Technology |
Blade Battery |
Blade Battery |
Blade Battery |
| Battery brand |
BYD |
BYD |
BYD |
| Battery Pack Warranty |
No age or mileage limit for the first owner (liability exemption clause is subject to official regulations) |
No age or mileage limit for the first owner (liability exemption clause is subject to official regulations) |
No age or mileage limit for the first owner (liability exemption clause is subject to official regulations) |
| Battery capacity (kWh) |
18.32 |
18.32 |
18.32 |
| Battery Charging |
Fast charge 0.5 hours Slow charge 5.55 hours |
Fast charge 0.5 hours Slow charge 5.55 hours |
Fast charge 0.5 hours Slow charge 5.55 hours |
| ●Fast charging port |
●Fast charging port |
●Fast charging port |
| Maximum fast charging power (kw) |
17 |
17 |
17 |
| Fast charging port location |
Right fuel tank |
Right fuel tank |
Right fuel tank |
| Slow charging port location |
Right fuel tank |
Right fuel tank |
Right fuel tank |
| Battery Temperature Management System |
●Low temperature heating |
●Low temperature heating |
●Low temperature heating |
| ●Liquid Cooling |
●Liquid Cooling |
●Liquid Cooling |
| VTOL mobile power station function |
●Standard |
●Standard |
●Standard |
| VTOL maximum external discharge power |
3.3kW |
3.3kW |
3.3kW |
| Minimum allowable value of external discharge power (%) |
15 |
15 |
15 |
| Gearbox |
| Gearbox Description |
E-CVT continuously variable transmission |
E-CVT continuously variable transmission |
E-CVT continuously variable transmission |
| Number of gears |
Continuously variable speed |
Continuously variable speed |
Continuously variable speed |
| Gearbox Type |
Electronic Continuously Variable Transmission (E-CVT) |
Electronic Continuously Variable Transmission (E-CVT) |
Electronic Continuously Variable Transmission (E-CVT) |
|
Chassis/Steering |
|
|
| Drive mode |
Front front drive |
Front front drive |
Front front drive |
| Front suspension type |
McPherson independent suspension |
McPherson independent suspension |
McPherson independent suspension |
| Rear suspension type |
Trailing arm torsion beam non-independent suspension |
Trailing arm torsion beam non-independent suspension |
Trailing arm torsion beam non-independent suspension |
| Steering type |
Electric power assist |
Electric power assist |
Electric power assist |
| Vehicle structure |
Load-bearing |
Load-bearing |
Load-bearing |
| Wheels/Brakes |
| Front brake type |
Ventilated disc |
Ventilated disc |
Ventilated disc |
| Rear brake type |
Solid disc |
Solid disc |
Solid disc |
| Parking brake type |
Electronic parking brake |
Electronic parking brake |
Electronic parking brake |
| Front tire size |
215/55 R17 |
215/55 R17 |
215/55 R17 |
| Rear tire size |
215/55 R17 |
215/55 R17 |
215/55 R17 |
