PiWinEnergy 7KW 11KW 22KW AC EV Home Charger With Type 2 Plug, Home Charging Station
Contact us for the latest price, configuration and availability.
Vehicle specification, options and delivery terms are confirmed with your quotation.
About this vehicle
Vehicle overview
Configuration details
Full configuration
Scroll across to compare the listed editions. Confirm the exact edition and equipment with your quotation.
| Power supply | 3P+N+PE |
| Input voltage | 400VAC±10%(50Hz±5Hz) |
| Output voltage | 400VAC±20% |
| Output current | 16A/32A |
| Output power | 11KW/22KW |
| Electric energy measurement | Accuracy Class 1 energy meter |
| HMI | 4.3 inch LCD |
| Plug cable length | 5m |
| Communication | Ethernet/WIFI |
| Protocol | OCPP-1.6 (JSON) |
| Insulation resistance | 1000VDC≥10MΩ |
| Dielectric strength | AC2500≤10mA(input/output to ground) |
| Connector type | IEC 62196-2 |
| Standards | IEC 61851-1, IEC 62196-1/2 |
| Shell color | Metallic grey |
| Shell material | (PC+ABS)-Blend |
| Installation method | Wall-mount/Pole-mount |
| Dimensions(W*H*D) | 300mm*420mm*153.8mm |
| Ingress protection | IP55 |
| Operating temperature | -30℃-60℃ |
| Storage temperature | -40℃-80℃ |
| Altitude | ≤2000m |
| Humidity | ≤95%, non-condensing |
