| غرض / مواصفات |
ايون واي بلس 410 — European Version (WVTA Reference) |
| BASIC INFORMATION |
| Model Designation |
ايون واي بلس 410 (Exclusive / Premium trim) |
| نوع المركبة |
بطارية السيارة الكهربائية (بيف), سيارات الدفع الرباعي المدمجة / Crossover |
| نمط الجسم |
5-باب, 5-سيات الدفع الرباعي |
| الطول × العرض × الارتفاع (المليمتر) |
4535 × 1870 × 1650 |
| قاعدة العجلات (المليمتر) |
2750 |
| أمام / Rear Track (المليمتر) |
1600 / 1600 |
| أمام / Rear Overhang (المليمتر) |
898 / 887 |
| Min. Ground Clearance (المليمتر, full load) |
150 |
| Turning Radius / Turning Circle (m) |
5.5 / 11.0 m diameter |
| أقبل / Departure Angle (°) |
18 / 27 |
| Kerb Weight (ك جم) |
1670 |
| Gross Vehicle Weight (ك جم) |
2180 |
| ماكس. Roof Load (ك جم) |
75 |
| Trunk Volume (L) |
405 – 1200 (40/60 split-fold) |
| Drive Type |
دفع أمامي (Front-Wheel Drive) |
| Number of Doors / مقاعد |
5 / 5 |
| Euro Class / Energy Label |
Zero-emission BEV (A1 VES band) |
| PERFORMANCE |
| نوع المحرك |
Permanent Magnet Synchronous Motor (PMSM) |
| Motor Model / Code |
TZ184XYA2002 |
| ماكس. قوة (كيلوواط / حصان) |
150 كيلوواط / 204 حصان (EU rating 136 hp variant also available) |
| ماكس. عزم الدوران (نانومتر) |
225 |
| السرعة القصوى (كم / ساعة) |
150 (EU limited) |
| Acceleration 0–100 km/h (s) |
8.5 |
| ماكس. Motor Speed (دورة في الدقيقة) |
14,000 |
| انتقال المرض |
1-سرعة أوتوماتيكية, single-speed reduction gear |
| التروس |
1 (تلقائي) |
| Drivetrain Layout |
محرك أمامي, القيادة الأمامية |
| Steering System |
Electric Power Steering (ربحية السهم), rack and pinion |
| BATTERY & RANGE |
| تكنولوجيا البطارية |
بطارية المجلة (LFP – Lithium Iron Phosphate) |
| Battery Chemistry |
LiFePO4 (Lithium Iron Phosphate) |
| Battery Capacity – Gross (كيلووات) |
50.66 |
| Battery Voltage (V) |
374.4 (system ~400 V) |
| Battery Location |
Below floor, under-floor enclosure |
| Range – NEDC (كيلومتر) |
410 |
| Range – WLTP Combined (كيلومتر, est.) |
310 – 330 (EU type-approval pending confirmation) |
| Range – WLTP City (كيلومتر, est.) |
≈ 430 (city-biased) |
| Energy Consumption – WLTP (كيلوواط ساعة / 100 كم) |
≈ 16.5 – 17.5 (est.) |
| CO₂ Emissions (g/km) |
0 (بيف) |
| Battery Low-Temperature Heating |
● |
| CHARGING |
| Charging Interface – AC |
نوع 2 (Mennekes, European standard) |
| Charging Interface – DC |
CCS2 (Combined Charging System) |
| On-Board AC Charger (max.) |
7 كيلوواط (single-phase) / 11 كيلوواط (3-phase capable) |
| AC 0–100% Charging Time (7 كيلوواط) |
≈ 7.5 h |
| AC 0–100% Charging Time (11 كيلوواط) |
≈ 5 h (est.) |
| DC Max. Fast Charging Power (كيلوواط) |
80 – 90 كيلوواط |
| DC 20–80% Charging Time |
≈ 40 دقيقة |
| DC 10–80% Charging Time (est.) |
≈ 45 دقيقة |
| DC Quick-Charge Time (80 كيلوواط, 10→80%) |
≈ 45 دقيقة |
| V2L (Vehicle-to-Load) |
— (not available on 410 trim) |
| Charging Cable |
نوع 2 cable included |
| CHASSIS & BRAKES |
| Front Suspension |
MacPherson Independent (coil spring + anti-roll bar) |
| Rear Suspension |
Torsion Beam Semi-independent (coil spring) |
| Front Brakes |
قرص جيد التهوية |
| Rear Brakes |
قرص صلب |
| القيمه المطلقه (نظام الفرامل المانعة للانغلاق) |
● |
| EBD (Electronic Brake Force Distribution) |
● |
| ESP (Electronic Stability Program) |
● |
| VDC (Vehicle Dynamics Control) |
● |
| TCS (Traction Control System) |
● |
| HHC (مساعد الانطلاق على المنحدرات) / إتش دي سي |
● / — |
| EPB (Electronic Parking Brake) + Auto Hold |
● / ● |
| i-Pedal (One-Pedal Driving Mode) |
● |
| Steering Type |
Rack and pinion, electric power steering |
| Rims |
Aluminium alloy (17″ or 18″) |
| Tyre Specification |
215/50 آر 18 (215/55 R17 on base) |
| Spare Tyre |
Temporary / non-full-size |
| براني |
| Panoramic Sunroof (openable) + Electric Sunshade |
● |
| LED Headlights |
● |
| LED Daytime Running Lights (DRL) |
● |
| Rear Fog Lights |
● |
| Side Mirrors w/ Turn Signal Indicators |
● |
| Power Adjustable Side Mirrors |
● |
| Power Folding Side Mirrors |
● |
| Heated Side Mirrors |
● |
| Electric Hidden Door Handles |
● |
| Electric Tailgate (Power Tailgate) |
● |
| Rear Rain Wiper |
● |
| Roof Rails / Roof Rack Guide Rail |
● |
| Body Colours |
SongHua Yellow / Starry Green /Hyper Silver / Free Gray / Elegant Gray / أبيض قطبي / نايت شادو بلاك (market dependent) |
| أقبل / Departure Lighting |
— |
| داخل |
| Multi-Function Steering Wheel |
● (صوتي / الهاتف / cruise / info) |
| Steering Wheel Material |
PVC / Microfiber leather-trimmed |
| Steering Column Adjustment |
4-way adjustable |
| PVC / Synthetic Leather Seats |
● قياسي (Exclusive: PVC; قسط: upgraded) |
| Driver Seat – 6-way Power Adjustable |
● |
| Front Passenger Seat – 4-way Power Adjustable |
● |
| Driver’s Seat Back Fully Foldable |
● |
| Front Seat Ventilation |
● |
| Heated Front Seats |
— (سوق / trim dependent) |
| Second-Row 40/60 Split-folding Seats |
● |
| Rear Seat Centre Armrest |
● |
| Rear Seat Centre Headrest |
● |
| 10.25″ LCD Instrument Cluster |
● |
| 14.6″ Touch Control Central Screen |
● |
| الدخول بدون مفتاح & بدء التشغيل بدون مفتاح |
● |
| i-Pedal (Electronic Pedal) Mode |
● |
| Auto Anti-Glare Interior Rearview Mirror |
● (كهربائي) |
| 32-Color Interior Ambient Lighting |
● |
| Front 12V Power Outlet |
● |
| أمام & Second-Row USB Ports (A+C) |
● |
| USB Port on Rearview Mirror (5V) |
● |
| أمام & Rear Windows One-Touch Up/Down (Anti-Pinch) |
● |
| Rear A/C Outlets |
● |
| Dual-Zone / Automatic A/C |
● (مكيف السيارة) |
| PM2.5 Cabin Filter |
● |
| Mobile Phone Wireless Charging |
● |
| INFOTAINMENT & CONNECTIVITY |
| Audio & Video System (Multi-language) |
● (EN/TH/ID/MS/zh-TW/VI/ES/PT/AR) |
| Bluetooth® Handsfree Phone System |
● |
| Speaker Count |
6 المتكلمون |
| أبل كاربلاي |
— / ○ (market dependent) |
| أندرويد أوتو |
— / ○ (market dependent) |
| Wi-Fi Hotspot |
— (not available on 410 trim) |
| Online Navigation |
● |
| Online Music |
● |
| جهاز التحكم عن بعد لتطبيق الهاتف المحمول |
● |
| 4-Zone / Multi-Zone Voice Recognition |
● (ADiGO smart voice) |
| Intelligent Voice Control |
● |
| 540° Panoramic HD Surround Imaging |
● (360° + underbody view) |
| SAFETY & SECURITY |
| Driver & Front Passenger Airbags |
● (2) |
| Front Side Airbags |
● (2) |
| Side Curtain Airbags (full coverage) |
● |
| Front Seat Belt Pretensioners & Force Limiters |
● |
| Front Seat Belt Reminder (Visual + Audible) |
● |
| Rear Seat Belt Reminder |
● |
| ISOFIX Child Safety Seat Anchors |
● |
| i-Size Child Seat Anchors |
● |
| TPMS (نظام مراقبة ضغط الإطارات) |
● |
| القيمه المطلقه + EBD + ESP + VDC + TCS |
● All standard |
| Braking Energy Recovery System |
● |
| Auto Hold |
● |
| Child Safety Locks (Rear Doors) |
● |
| Immobiliser & Anti-Theft Alarm |
● |
| e-Call Emergency Call |
● (EU requirement) |
| GLONASS / GPS |
● |
| 360° Panoramic / HD Surround Camera |
● |
| أمام & Rear Parking Radar |
● |
| Rearview Mirror with USB (dash cam ready) |
● |
| عدس (ADiGO DRIVING ASSISTANCE) |
| Processing Chip |
Mobileye EyeQ4 (2 TOPS compute) |
| Sensors: Radar / Camera / Ultrasonic |
3 / 5 / 12 |
| لجنه التنسيق الاداريه (Adaptive Cruise Control w/ Stop & Go) |
● |
| ICA (Intelligent Cruise Assist) |
● |
| TJA (Traffic Jam Assist) |
● |
| AEB (الكبح التلقائي في حالات الطوارئ) |
● |
| FCW (نظام التحذير من الاصطدام الأمامي) |
● |
| LDW (تحذير مغادرة المسار) |
● |
| أيضًا (Lane Keeping Assist) |
● |
| TSR (Traffic Sign Recognition) |
● |
| BSD (Blind Spot Detection) |
● |
| DOW (Door Open Warning) |
● |
| RCTA (Rear Cross Traffic Alert) |
● |
| RCW (نظام التحذير من الاصطدام الخلفي) |
● |
| IHBC (Intelligent High Beam Control) |
● |
